1 Year Cloud Storage + 100 Message/Month
3 Month 10MB/Month SIM Card
Power Supply
Micro USB Cable
Antennas ( Cellular 4G/3G/2G, WiFi 2.4/5 )

Build, Innovate and Produce Endless IoT Applications. Features 4G/3G/2G LTE Cellular connectivity. The Blink'r Dev. Board can transform your technology into a Smart IoT Device. A powerful process for intensive computing and rich-peripherals for connecting sensors, actuators and motors coupled with a complete back-end to get your prototype up and running fast.


Dev Board Spec

Documentation :: References :: User Manual


CPU Type
CPU Cores
CPU Bus
CPU Speed
Memory
Flash
Lithium Power
Real-time-Clock
USB 2.0
FM Radio
USB/OTG
I2C
I2S

GPIO
SPI

Cortex A53
4
64-bit
1.3GHz
1GB LPDDR3
8GBeMMC
Capable
Yes
3 Port
YES
1 Port
2 I2C Port
1 I2S Port
12 General purpose IO
1 SPI Port

UART
SIM
Micro SD
ADC
Network
Display
Audio
Video
Camera
Key
Cellular Data
Wireless
Bluetooth
GPS
Power Supply

4 UART Port
1 Dual SIM Port
1 Micro SD Port
1 12 bit ADC
10/100M port+WiFi+BT4.0
1080P Port
Speaker/MIC/35mm Jack
HDMI 1080 P30 Port
2 4-lane CSI Port + Integrated ISP
12 keypads Port
2G/3G/4G LTE
2.4 GHz/5GHz, WLAN 802.11 b/g/n
Bluetooth 4.1, Bluetooth Low Energy ( BLE )
GPS/BeiDou/AGPS
____ __ __



Layout

Screen Shot 2017-08-14 at 11.44.47 PM.png
